|Output Quantity||200ml – 1000ml|
|Filler Accuracy||± 5 gm|
|Pack / Quantity Range
Min. Bag size (W x L) approx
Max. Bag size (W x L) approx
100 mm x 135 mm
170 mm x 265 mm
|Packaging Material||Co-extruded 3 or 5 Layer PE Based
or Laminated 65 to 120 microns
|Film Reel||Core dia 76 mm & Reel
diameter 300 mm max.
|Input Supply||380 V AC, 50 Hz, 3 ph + N + G|
|Connected Load||5.5 KVA|
|Peak Power Rating||5 KW|
|Flow Rate||150 ltr/hr|
|Temperature Range||6° to 10°C maintained|
|Minimum Pressure||2 bar|
|Machine Dimensions(W x D x H) approx.||735 mm x 640 mm 2760 mm|
|Weight||450 kgs (Net)|
|Suitable for Packing||Edible Oil, Ghee, Vanaspati,
Pasteurised Fruit Pulp,
Mango Pulp,Fresh Cream,
Water & Lubriction Oil.
Our machines can be equipped with different types of date coding devices such as ink jet printers, thermal date coding devices etc. The date coding device is used to print precise, easy-to-read and indelible date codes and batch codes that are not only critical for many industries but are also mandatory by many Governments around the world. These devices have the ability to print use-by dates, best-before dates and batch codes.
