| Output Quantity | 250ml – 1000ml |
| Output | 1500 ~ 2000 packs/hr |
| Filler Accuracy | ± 5 gm |
| Pack / Quantity Range Min. Bag size (W x L) approx Max. Bag size (W x L) approx |
80 mm x 150 mm 175 mm x 270 mm |
| Packaging Material | Co-extruded 3 or 5 Layer PE Based or Laminated 65 to 120 microns |
| Film Reel | Core dia 76 mm & Reel diameter 300 mm with 40 mm-690mm |
| Electrical Requirement | |
| Input Supply | 208/240 V3 phase, 60 Hz, 3 ph + N + G |
| Connected Load | 5.5 KVA |
| Peak Power Rating | 5 KW |
| Cooling Water | |
| Flow Rate | 2000 ltr/hr |
| Temperature Range | 6° to 10°C maintained |
| Minimum Pressure | 6 bar |
| Machine Dimensions(W x D x H) approx. | 1800 mm x 1920 mm 1050 mm |
| Weight | 700 kgs (Net) |
| Suitable for Packing | Edible Oil, Pasteurised Milk, Pasteurised Fruit Pulp, Cream, Butter Oil & Water |
|
Types of Products        |
Our machines can be equipped with different types of date coding devices such as ink jet printers, thermal date coding devices etc. The date coding device is used to print precise, easy-to-read and indelible date codes and batch codes that are not only critical for many industries but are also mandatory by many Governments around the world. These devices have the ability to print use-by dates, best-before dates and batch codes.
