| Output Quantity | 100ml – 1000ml |
| Output | 4800~9000 packs/hr. |
| Filler Accuracy | ± 0.3% |
| Pack / Quantity Range Min. Bag size (W x L) approx Max. Bag size (W x L) approx |
100 mm x 130 mm 170 mm x 265 mm |
| Packaging Material | Co-extruded 3 or 5 Layer PE Based or Laminated 85 to 120 microns |
| Film Reel | Core dia 76 mm & Reel diameter 300 mm max |
| Electrical Requirement | |
| Input Supply | 380 V AC, 60 Hz, 3 ph + N + G OR 220/240/480V 50 Hz |
| Connected Load | 6 KVA |
| Peak Power Rating | 5 KW |
| Cooling Water | |
| Flow Rate | 150 ltr/hr |
| Temperature Range | 6° to 10°C maintained |
| Minimum Pressure | 1~6 bar |
| Air Requirement (Optional) | |
| Air Pressure | 6 bar constant dry air |
| Machine Dimensions(W x D x H) approx. | 1645 mm x 770 mm 3005 mm |
| Weight | 1200 kgs (Net) |
| Suitable for Packing | Edible Oil, Ghee, Vanaspati, Pasteurised Fruit Pulp, juices, Fresh Cream, Pasteurised Milk, Water & Lubriction Oil. |
|
Types of Products      |
Our machines can be equipped with different types of date coding devices such as ink jet printers, thermal date coding devices etc. The date coding device is used to print precise, easy-to-read and indelible date codes and batch codes that are not only critical for many industries but are also mandatory by many Governments around the world. These devices have the ability to print use-by dates, best-before dates and batch codes.
