| Output Quantity | 250ml – 500ml or 500ml – 1000ml |
| Output | 700-900 packs/hr for liquid or 500-600 packs/hr for viscous liquids |
| Filler Accuracy | ± 5 ml |
| Pack / Quantity Range Min. Bag size (W x L) approx Max. Bag size (W x L) approx |
110 mm x 170 mm 180 mm x 260 mm |
| Packaging Material | Co-extruded 3 or 5 Layer PE Based or Laminated 100 to 140 microns |
| Film Reel | Core dia 76 mm & Reel diameter 300 mm max |
| Electrical Requirement | |
| Input Supply | 380 V AC, 60 Hz, 3 ph + N + G OR 220/240/480V 50 Hz |
| Connected Load | 6.5 KVA |
| Peak Power Rating | 6 KW |
| Cooling Water | |
| Flow Rate | 150 ltr/hr |
| Temperature Range | 6° to 10°C maintained |
| Minimum Pressure | 2 bar |
| Air Requirement (Optional) | |
| Air Pressure | 6 bar constant dry air |
| Air Comsumption | 800 ltr/min |
| Machine Dimensions(W x D x H) approx. | 870 mm x 915 mm 1800 mm |
| Weight | 350 kgs (Net) |
| Suitable for Packing | Glue, Milk, Edible Oil, Butter Oil, Shampoo, Pasteurised Fruit Pulp, Mango Pulp, Fresh Cream, Chees, Yougurt, Water, ketchup, Mayonnaise, Lubriction Oil, as well as all kind of semi-viscous & liquid product |
|
Types of Products  |
Our machines can be equipped with different types of date coding devices such as ink jet printers, thermal date coding devices etc. The date coding device is used to print precise, easy-to-read and indelible date codes and batch codes that are not only critical for many industries but are also mandatory by many Governments around the world. These devices have the ability to print use-by dates, best-before dates and batch codes.
